Dahua DHI-NVR1108HS-8P-S3/H 8-channel NVR Video Recorder
The Dahua DHI-NVR1108HS-8P-S3/H is a powerful and compact 8-channel NVR designed for seamless video surveillance solutions. With integrated PoE (Power over Ethernet) ports, it simplifies installation and supports high-definition video recording, making it an ideal choice for small to medium-sized applications like homes, offices, and retail spaces.
Key Features
8-Channel Input Support
- Connects up to 8 IP cameras simultaneously.
- Compatible with resolutions up to 8MP (4K) for superior image clarity.
Built-in 8-Port PoE
- Integrated 8 PoE ports eliminate the need for external power supplies for cameras.
- Reduces cable clutter and simplifies setup for a clean and efficient installation.
High-Definition Video Recording
- Supports recording in resolutions up to 4K.
- Provides clear and detailed footage for precise monitoring and playback.
Advanced Video Compression
- Features H.265+ video compression technology, reducing storage and bandwidth usage while maintaining excellent video quality.
- Backward compatibility with H.264 compression.
Ample Storage Capacity
- Supports up to 2 SATA hard drives, each with a maximum capacity of 8TB, providing up to 16TB of total storage.
- Optimized for long-term video storage with efficient compression.
Multiple Video Outputs
- Equipped with both HDMI (up to 4K) and VGA (up to 1080p) video outputs for flexible display options.
- Simultaneous live view and playback options.
Remote Monitoring
- Access live feeds and playback remotely via Dahua’s DMSS mobile app or web browser.
- Supports ONVIF compatibility, allowing integration with third-party devices.
Intelligent Video Functions
- Incorporates features like motion detection, tripwire, and intrusion detection for enhanced situational awareness.
- Supports alarm triggers for event-based notifications.
User-Friendly Interface
- Intuitive GUI with easy navigation for efficient configuration and operation.
- Supports multi-user access with customizable permissions.
Efficient Backup Options
- Backup footage via USB ports or over the network.
- Supports exporting recordings in standard formats for easy sharing and storage.
Specifications
| Feature | Details |
|---|---|
| Channels | 8 |
| Supported Resolution | Up to 8MP (4K) |
| Compression | H.265+, H.265, H.264+, H.264 |
| PoE Ports | 8 (IEEE 802.3af/at compliant) |
| Video Outputs | HDMI (up to 4K), VGA (up to 1080p) |
| Storage | 2 SATA HDDs (up to 8TB each) |
| Ethernet | 1 RJ45 port (10/100Mbps) |
| USB Ports | 2 (1 front, 1 rear) |
| Mobile App | DMSS |
| Power Supply | DC 48V, 1.5A |
| Power Consumption | ≤10W (without HDD) |
| Operating Temperature | -10°C to +55°C (14°F to 131°F) |
| Dimensions | 260mm × 224.9mm × 47.6mm |
| Weight | 1.6 kg (without HDD) |
Applications
- Residential Surveillance: Secure homes with high-definition recording and remote monitoring.
- Small Businesses: Ideal for retail stores, offices, and workshops.
- Healthcare Facilities: Monitor sensitive areas with reliable video storage.
- Educational Institutions: Enhance security in schools and campuses.
